2. 6.5 inch 16:9 Digital High Definition TFT LCD 800*480 touchscreen, motorized panel
3. 3D graphic interface - Three panel keys color selectable: Blue, Red, Green

4. All-Region DVD/CD disc playback supported - DVD / VCD / CD / MP3 / MPEG4 / DIVX / CD-R / WMA / JPEG

5) Built-in ESP Anti-shock function

6) Built-in Radio: AM FM, Support RDS

7) Built in TV tuner, PAL/NTSC or SECAM compatible
8) Build in Bluetooth for hand free call, history log, dial keyboard
9) Built-in GPS navigation. Dual zone function: you can listen to the music or the radio while in navigation viewing the map
10) Support iPod iPhone
11) Support USB/ SD card slot - 2 SD slots: one for GPS map, one for music and other files - 1 USB jack and SD card slots for MP3, WMA, MP4, AVI, JPEG files
12) Easy installation: exactly the same dimension with the original car DVD, no modification needed
13) Special cable connector for the original car Same style with the car
14) One channel AUX Video input, two channel Video output
15) Support Reverse Camera Control - Parking Rear view camera iutput

16) Support Steering Wheel Control

17) Virtual 6 disks CDC: V-6 disc changer memory (6 disc music can be memory in the unit while you are listening the music)
18) Built in game function (optional)
19) Buil in 50W*4 Hi-Fi Power Amplifier

Accessories: remote control, power line, iPod cable, GPS antenna, USB cable, Iron Rod

GPS Navigation:

Operation system	Win CE 5.0
GPS Processor	Samsung 2440 Dual Core: 400MHz +533Mhz(one for GPS Navigating, the other for Multimedia function)
SDRAM / ROM	128MB / 128MB Flash
Chip module	SiRF Star III/ Ultra X-codec
GPS receivers channels	20
Maps Supported	Common brand: PolNav, Igo, Route66, Tom-Tom, VietMap Support 3D Maps
	Version: PND
	video display required: 800 * 480
GPS Resolution Output	800*480
Voice guidance	YES. Actual voice and display language depends on GPS software package
TMC	NO
GPS Antenna	Yes, Included

DVD Playback:

Discs supported:	DVD, CD, VCD, CD-R/RW, CD+R/RW, DVD-R/RW
DVD Disc Region Supported	All Regions(1-6)
Play Mode	repeat chapter/title/off/RDM
Media Formats Supported:	Audio: MP3, WMA Picture: JPEG Video: MPEG 1/2, AVI, DIVX, etc
Screen & Panel:
Screen	16:9 Digital Touchscreen, Definition 800*480
Panel	Fixed and Undetachable
Color system	PAL/ NTSC,AUTO

Language

Main Menu OSD Language	English/Chinese
GPS Menu Languages	English/Chinese
DVD Control Language	English/Chinese

TV

Digital TV	NO
Analog TV	Yes
Video Output	Yes

Radio

Radio Frequency	AM Frequency/ Step: 522-1620KHz/9KHz; 530-1720KHz/ 10KHz
	FM Frequency/ Step: 87.5-108MHZ/ 0.1MHz
RDS	YES
XM Radio	NO
HD Radio	NO
Saving Station	Support Auto and Manual Saving stations

Bluetooth

Version	Bluetooth 2.0 Support A2DP(Play music from Cellphone)
Bluetooth Handsfree	YES
Built-in microphone	YES
Other Functions	Received Call, Dialed Call, Missed Call
Phone book	YES( not all cell phones are supported. e.g: cellphone of old Bluetooth protocol may not be accessed to read contact details , we do not promise it works with every cellphone, just add here for reference)

iPod Control

Support Generation	Most iPods are supported（but iPod shuffle, iPod 1-4G,Latest iPod/ iPhone may be not supported)
Support Music/Video	play Music
Controlling on the Unit screen	Yes
Show Title/Artist/Playlist	YES
Charge up the iPod	NO
iPod cable length	90CM

Other Functions:

Auto Reverse Camera Input	YES
Anti-Shock	YES, Built-in Electronical /Mechanical anti-shock system
CAN-BUS	NO
Start-up Car Logo	YES
E-book Reader	YES, support txt file
EQ	POP,CLASSIC,ROCK,JAZZ,FLAT
Dual-Zone Playback	YES. Front and Rear independent playback
GPRS wireless network	NO
GPS Dual-Zone	YES, Listen to Music/Radio while navigation
IPAS	NO
Steering wheel control	YES
PIP	NO
Max output of power	4 * 50w
Mobile Office software package	NO
TPMS	NO
WIFI wireless network	NO
Virtual CDC	NO

Video/Audio in/out:

Video in/out	1 Aux Video In; 1 Camera Video In; 2 Video Out
Audio in/out	2 RAC Input; 4 RCA Output
Subwoofer Out	YES
CDC port	NO
Aux Input	1 * AUX Input
SPDIF-Out	NO

USB&SD

USB Interface	1 Mini USB port
	Position: Front
	USB hard drive: NO
SD slot	Music SD slot:  Position: Front, Support Max.16G SD card
	Navi SD slot:  Position: Front, Support Max. 2G SD card
	Notice, the parameter is for all model name like QL-MZD501( "5" Series), some models do not have music SD slot, all are subject to the real pictures above
Multi-Media playback supported	MP3, MP4, AVI,etc

Operating Environment

Voltage requirement	12V
Current requirement	1.5A
Operating temperature range	-40°C-75°C

Accessories

TV Antenna	1 piece included
GPS Antenna	1 piece included
Remote control	1 piece included
Wire/Cable	1 iPod cable 1 power harness 1 USB cable
User Manual	1 piece (in English)
Touch Pen	1 piece included

Packing

GIFTBOX SIZE	34*31*20CM
G.W.	6.0KG
